HiSpeed
Air Cooled Handheld Laser Welding Machine
A compact, ultra-lightweight handheld laser welding machine with an efficient air-cooled system. Delivers stable performance and features a user-friendly interface—perfect for portable, on-the-go welding tasks.
Key Features
Air-Cooled System: No water cooling required, ensuring hassle-free operation and maintenance.
Compact & Portable: Weighing only 46kg, it’s designed for easy mobility and outdoor welding tasks.
Stable Performance: Delivers consistent and reliable welding quality in various conditions.
Ultra-Lightweight Handheld: The handheld unit weighs just 660g, reducing operator fatigue and improving precision.
User-Friendly Interface: Features a 7-inch large control screen with a streamlined mode for intuitive operation.
Technical Specifications
| Laser Power | 700W/1000W/1500W/2000W |
| Welding Control System | HISPEED |
| Welding Head | HISPEED |
| Weld Head Wavelength | 1080±10nm |
| Range of Adjusting Focus | ±10mm |
| Scan Width | ≤6mm |
| Scanning Frequency | ≤300HZ |
| Laser Interface | QBH |
| Tracheal Interface | PU OD 6.0mm ID4.0mm |
| Pressure | ≤1.5 Mpa |
| Protective Gas | Nitrogen |
| Specification of Protective mirror | 18*2mm |
| Working Mode | Continuous, fish scale, interval |
| Weld Head Weight | 660g |
| Working Environment Temperature | ﹣20～+40℃ |
| Working Environment Humidity | ≤70% |
| Power supply | 110V/60Hz or 220V/50Hz |
Applications
Automotive
Metal Cabinet
Shipbuilding
Shelf Manufacturing
Lighting Manufacturing
Home Appliance Manufacturing
Window Manufacturing
Elevator Manufacturing
